Product Description


Downloads

UM_Terra-Aria POB_all series_low.pdf
Technical specification
LED type
CW+WW (5W)
Number of LEDs
5 (2700K) +5 (6500K)
Lumen MAX
2200
Lenses
15°
15° x 30°
25°
40°
60°
Filters
None
f 17° tilt
f34° tilt
f 60°
f 65°
f 100°
f 8°x 60°
Control type
Protocol USITT DMX512 - RDM
DMX - RDM + DALI
Functions
RDM/DRS
Input range
20 - 48 VDC
Power (W)
16 W
IP protection rating
IP 67
68 optional
Mounting systems
Surface
Truss (optional)
Dimensions d x h (mm)
134 x 115
Weight (Kgs)
2,7
Materials
Ultra clear 10mm tempered glass
Case
Aluminium - Marine Grade (optional)
Aisi 304 (standard)
Aisi 316 (optional)
Aluminium (optional)
