Product Description


Downloads

UM_SMART series_low.pdf

ART.205210 - SMART MAX WB.zip
Technical specification
LED type
CW+WW (5W)
Number of LEDs
15 Warm White (2700K) + 15 Cool White (6500K) NICHIA-NVSL219C
LED expected lifetime (hrs)
50000
Lumen MAX
4500
Lenses
10°x30°
12°
24°
36°
Filters
None
f 60°
f 100°
f 12°x 60°
Connectors and cables
Main Power: 3x1,5mm cable
DMX signal: 3pin IP67 connector (male-female)
Control type
Protocol USITT DMX512 - RDM
Protocol USITT DMX512 - RDM + Wireless (on request)
Functions
RDM/DRS
Dedicated DMX channel for white balance from 2700K to 6500K
DMX or Auto Mode with Master-Slave function
Intelligent temperature control
Continuous dimming 0-100%
Smooth dimming function
Halogen simulation
Flicker-free function
Setup
RDM/DRS
DMX channels
4ch - 2ch - 1ch
Input range
100 - 240 VAC; 47/63 Hz
Power (W)
44
Current
Materials
Ultra clear 4mm tempered glass
PMMA lenses
All aluminium alloy
Polyester powder coated
Mounting systems
Surface
Truss (optional)
Marine Grade treatment
None
Yes
Tilt
175°
IP protection rating
IP 67
Sizes l x p x h (mm)
205x110x235
Weight (Kgs)
3,2
Colour finishing
Grey RAL 9006 (standard)
A - Anti glare SM30-BD
None
Yes
