Product Description



Downloads

UM_STADIO series_low.pdf
Technical specification
LED type
High Power NICHIA NVSW319
WHITE 3000K
WHITE 4000K
WHITE 5750K
Number of LEDs
288
LED expected lifetime (hrs)
50000
Lumen MAX
>100000
Lenses
15°
30°
50°
120° no lens
Control type
Plug-in
Input range
100 - 277 VAC; 47/63 Hz
Power (W)
700
Mounting systems
Surface
Truss (optional)
Marine Grade treatment
None
Yes
IP protection rating
66
Sizes l x p x h (mm)
820 x 180 x 455
Weight (Kgs)
21
Colour finishing
Grey RAL 9006 (standard)
