Technical specification
| Lighting source | |
|---|---|
LED type
|
Hi-Power NICHIA NVSW319AT
BIANCO 3000 K
WHITE 4000 K
WHITE 5750 K
|
Number of LEDs
|
240
|
Lumen MAX
|
84000
|
| Optics | |
Lenses
|
6°
12°
12°x48°
20°
30°
45°
60°
|
| Control | |
Control type
|
Plug-in
|
| Functions and Setup | |
Functions
|
N/A
|
| Power supply | |
Input range
|
100 - 277 VAC; 47/63 Hz
|
Power (W)
|
580
|
| Physical | |
Mounting systems
|
Surface
Truss (optional)
|
Marine Grade treatment
|
None
Yes
|
IP protection rating
|
IP 65
|
Sizes l x p x h (mm)
|
675 x 285 x 550
|
Weight (Kgs)
|
28
|
Colour finishing
|
Grey RAL 9006 (standard)
|
