Product Description

Ultra small form factor LED linear bar with n.7 (2700K) + n. 7 (6200K) LEDs bianchi. External Power Supply and Driver. With 20mm lenses. IP 67 protection rating. Dimmable version. Standard 100 cm.

Downloads

UM_Slimbar Plus-Flat_art-2012-2014-1710-11-12.pdf
Technical specification
LED type
CW+WW (5W)
Number of LEDs
14 (2700K-6200K)
Lumen MAX
1000@4000K
Lenses
10°x30°
12°
24°
36°
Filters (optional)
None
Elliptical projection filter 60° x 1° (1° = native lens) horizontal
Control type
External Control Driver
Input range
CV 48 VDC
Power (W)
6,5
Mounting systems
Surface
Truss (optional)
IP protection rating
67
Sizes l x p x h (mm)
525x40x60
Weight (Kgs)
1
Colour finishing
Anodized light grey
Marine Grade treatment
None
SB/P PILOT PLUS M DALI (art.524480)
No
Yes
SB/P PS PLUG-IN 320 M (art.532480)
No
Yes
SB/P PS PLUG-IN 60 M (art.560480)
No
Yes
SB/P PS PLUG-IN 150 M (art.515480)
No
Yes
SB/PILOT M DALI (art.533480)
No
Yes
SPS/P150-50 M (art.548150)
No
Yes
SPS/P320-50 M (art.548320)
No
Yes
SPS/P60-50 M (art.548060)
No
Yes
SB/P PILOT MAX M DALI (art.525480)
No
Yes
