Product Description
Hi Power wash LED Par Colorchanger. IP 67 protection rating. 14 RGBnW LEDs. Fixture with DRS-RDM control.
Technical specification
| Lighting source | |
|---|---|
LED type
|
RGB-NW (white 4000K)
|
Number of LEDs
|
14 (5050-20W) RGB-NW (White 4000K)
|
LED expected lifetime (hrs)
|
50000
|
Lumen max (lm)
|
9500
|
Red lumen (lm)
|
1950
|
Green lumen (lm)
|
3500
|
Blu lumen (lm)
|
600
|
White lumen (lm)
|
3500
|
| Optics | |
Lenses
|
8°
10°x50°
15°
15°x30°
25°
40°
60°
|
Filters (optional)
|
None
Elliptical projection filter 60° x n° (n° = native lens) horizontal
Elliptical projection filter n° x 60° (n° = native lens) vertical
|
| Connections | |
Connectors and cables
|
Main Power: 3x1mm cable H05 1,5mt
DMX signal: 4pin IP67 connector (male-female)
|
Connettori e cavi (optional)
|
Cable: type and length (optional)
|
| Control | |
Control type
|
DMX - RDM
DMX - RDM + Wireless (on request)
|
| Functions and Setup | |
Functions
|
Dedicated DMX channel for white balance from 2900K to 13000K
DMX or Auto Mode with Master-Slave function
Intelligent temperature control
Continuous dimming 0-100%
Smooth dimming function
Halogen simulation
CYM simulation
Flicker-free function
|
Setup
|
RDM/DRS
|
DMX channels
|
9ch - 6ch - 5ch - 4ch
|
| Power supply | |
Input range
|
100 - 277 VAC; 47/63 Hz
|
Power max (W)
|
105
|
Current
|
0,5A@230VAC
|
Power Factor
|
PF>0,95@230VAC
|
Inrush current
|
50A@230V
|
| Physical | |
Materials
|
Ultra clear 4mm tempered glass
PMMA lenses
All aluminium alloy
Polyester powder coated
|
Mounting systems
|
Surface
Truss (optional)
|
Colour finishing
|
Grey RAL 9006 (standard)
RAL 9006
Any RAL (optional)
Specify RAL
|
Marine Grade treatment
|
None
Yes
|
Tilt
|
360°
|
IP protection rating
|
67
|
Operating temperature
|
-30°C +45°C
|
Sizes l x p x h (mm)
|
247x190x300mm
|
Weight (Kgs)
|
4,6
|
| Optional/Accessories | |
Accessories - Barn door
|
None
Yes
|
| Uncategorized | |
PARLED300-BD (art.900113)
|
No
Yes
|
PARLED300-AG (art.900010)
|
No
Yes
|
PARLED300-SN (art.900200)
|
No
Yes
|
PARLED300-CL (art.900301)
|
No
Yes
|
PARLED300-GH (art.900422)
|
No
Yes
|
PARLED300-GH/SA (art.900423)
|
No
Yes
|
CLAMP/C (art.900516)
|
No
Yes
|
SAFETY WIRE/C (art.900523)
|
No
Yes
|
