Product Description
Downloads
Technical specification
| Lighting source | |
|---|---|
LED type
|
RGBW (20W)
|
Number of LEDs
|
24
|
Lumen max (lm)
|
14000
|
Red lumen (lm)
|
3000
|
Green lumen (lm)
|
5000
|
Blu lumen (lm)
|
900
|
White lumen (lm)
|
6000
|
| Optics | |
Lenses
|
6° Ultra Narrow
|
| Connections | |
Connectors and cables
|
Main Power: connettore 4pin IP67 (male-female)
Main Power: 3x1mm cable H05 1,5mt
|
| Control | |
Control type
|
DMX - RDM + Wireless (on request)
|
| Functions and Setup | |
Functions
|
RDM/DRS + touch control panel
|
| Power supply | |
Input range
|
100 - 240 VAC; 47/63 Hz
|
Power max (W)
|
210
|
| Physical | |
Mounting systems
|
Surface
Truss (optional)
|
Colour finishing
|
Black RAL 9005 (standard)
RAL 9005
Grey RAL 9006 (optional)
RAL 9006
White RAL 9010 (optional)
RAL 9010
Any RAL (optional)
Specify RAL
|
Marine Grade treatment
|
None
Yes
|
IP protection rating
|
67
|
Sizes l x p x h (mm)
|
613 x 185 x 415
|
Weight (Kgs)
|
19
|
