ARCHILED 200 M PLUG-IN (it.170100)
Hi Power wash LED Monochromatic fixture. 42 Hi-Power warm, neutral or coool white LEDs. On request: red, green, blue or amber. PLUG-IN version. Without touch control panel. IP 67 protection rating.
| LED type | WHITE 2700K, WHITE 3000K, WHITE 4000K, WHITE 6500K, RED, GREEN, BLUE, AMBER |
| Number of LEDs | 42 Hi-Power Nichia NVSW219CT Warm, Neutral, Cool White |
| Lumen max source (lm) | 9000 |
| Lenses | 8°, 10°x50°, 15°, 15°x30°, 25°, 40°, 60° |
| Filters (optional) | None, Elliptical projection filter 60° x n° (n° = native lens) horizontal, Elliptical projection filter n° x 60° (n° = native lens) vertical |
| Connectors and cables | Main Power: 3x1mm cable H05 1,5mt |
| Connettori e cavi (optional) | Cable: type and length (optional) |
| Control type | Plug-in |
| Input range | 100 - 240 VAC; 47/63 Hz |
| Power max (W) | 75 |
| Materials | Ultra clear 4mm tempered glass, PMMA lenses, Aluminium alloy housing , Polyester powder coated |
| Mounting systems | Surface, Truss (optional) |
| Colour finishing | Black RAL 9005 (standard) , Grey RAL 9006 (optional), White RAL 9010 (optional) 1, Any RAL (optional) |
| Marine Grade treatment | None, Yes |
| Tilt | 135° |
| IP protection rating | 67 |
| Operating temperature | -30°C +45°C |
| Sizes l x p x h (mm) | 270 x 100 x 303 |
| Weight (Kgs) | 5 |
| Product Category | Spot |
| AL200-AG (art.900013) | No, Yes |
| AL200-BD (art.900111) | No, Yes |
| ARCHILED CASEx4 (art. a richiesta) Flight Case | No, Yes |
| ARCHILED CASEx6 (art. a richiesta) Flight Case | No, Yes |
| CLAMP/C (art.900516) | No, Yes |
| FFB (art.900517) | No, Yes |
| SAFETY WIRE/C (art.900523) | No, Yes |
Documents
Hi Power wash LED Monochromatic fixture. 42 Hi-Power warm, neutral or coool white LEDs. On request: red, green, blue or amber. PLUG-IN version. Without touch control panel. IP 67 protection rating.
