Product Datasheet
Product Configurator
Compare
Request Information
Wishlist
Downloads
Product Description


Downloads
Technical specification
LED type
CW+WW (5W)
Number of LEDs
42x2 Cool White + 42x2 Warm White
Lumen MAX
7800
Lenses
120° beam
Control type
Protocol USITT DMX512 - RDM
Functions
RDM/DRS
Input range
Universal 100 - 240 VAC; 50/60 Hz
Power (W)
60 W
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Marine Grade treatment
None
Yes
IP protection rating
IP 67
Sizes l x p x h (mm)
1481 x 93 x 115
Weight (Kgs)
xxx
