Technical specification
LED type
RGBW5050MULTICHIP
Number of LEDs
112
Lumen MAX
2710
Red lumen (lm)
460
Green lumen (lm)
950
Blu lumen (lm)
260
White lumen (lm)
1300 (Cool White)
Lenses
120° beam
Control type
Protocol USITT DMX512 - RDM
Functions
RDM/DRS
Input range
100 - 240 VAC; 47/63 Hz
Power (W)
40
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Marine Grade treatment
None
Yes
IP protection rating
67
Sizes l x p x h (mm)
1004 x 93 x 115
Weight (Kgs)
3,5
