Product Description


Downloads
Technical specification
LED type
CW+WW (5W)
Number of LEDs
25 (2700K) + 25 (6500K)
Lumen MAX
20000
Lenses
15°
15° x 30°
25°
40°
60°
Filters
None
f 80°
f 100°
f 8°x 60°
Control type
Protocol USITT DMX512 - RDM
Protocol USITT DMX512 - RDM + Wireless (on request)
DMX - RDM + DALI
DMX - RDM + DALI + Wireless
Functions
RDM/DRS
RDM/DRS + touch control panel
Input range
100 - 240 VAC; 47/63 Hz
Power (W)
168
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Marine Grade treatment
None
Yes
IP protection rating
IP 67
Sizes l x p x h (mm)
1517 x 163 x 160
Weight (Kgs)
9,9
