Technical specification
LED type
RGBW5050MULTICHIP
Number of LEDs
10
LED expected lifetime (hrs)
50000
Lumen MAX
5670
Red lumen (lm)
1170
Green lumen (lm)
2300
Blu lumen (lm)
340
White lumen (lm)
2200
Lenses
15°
15°x30°
25°
40°
60°
Filters
None
f 60°
f 100°
f 8°x 60°
Control type
Protocol USITT DMX512 - RDM
Protocol USITT DMX512 - RDM + Wireless (on request)
Functions
RDM/DRS + touch control panel
Wireless DMX receiver
Input range
100 - 277 VAC; 47/63 Hz
Power (W)
70
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Any RAL (optional)
Marine Grade treatment
None
Yes
IP protection rating
67
Sizes l x p x h (mm)
632 x 163 x 160
Weight (Kgs)
4,5
