Product Description


Downloads
Technical specification
LED type
CW+WW (5W)
Number of LEDs
16 (2700K) + 16 (6500K)
Lumen MAX
8000
Lenses
15°
15° x 30°
25°
40°
60°
Filters
None
f 60°
f 100°
f 8°x 60°
Control type
Protocol USITT DMX512 - RDM
Protocol USITT DMX512 - RDM + Wireless (on request)
DMX - RDM + DALI
DMX - RDM + DALI + Wireless
Functions
RDM/DRS
Input range
100 - 240 VAC; 47/63 Hz
Power (W)
67
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
Black RAL 9005 (optional)
White RAL 9010 (optional)
Marine Grade treatment
None
Yes
IP protection rating
IP 67
Sizes l x p x h (mm)
1212 x 93 x 115 mm
Weight (Kgs)
xxx
Product Category
Linear Bar
