Product Description


Downloads
Technical specification
LED type
WHITE 2700 K
BIANCO 3000 K
WHITE 4000 K
WHITE 6500 K
RED
GREEN
BLUE
AMBER
Lumen MAX
12500
Lenses
15°
15° x 30°
25°
40°
60°
Filters
None
f 60°
f 100°
f 4° x 60°
Control type
Protocol USITT DMX512 - RDM
Protocol USITT DMX512 - RDM + Wireless (on request)
DMX - RDM + DALI
DMX - RDM + DALI + DMX - Wireless
Functions
RDM/DRS
Input range
100 - 240 VAC
Power (W)
84
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Marine Grade treatment
None
Yes
IP protection rating
IP 67
Sizes l x p x h (mm)
1484 x 93 115
Weight (Kgs)
xxx
