Product Description

Compact LED floodlight Monochromatic projector. 16 Monochromatic LEDs. 38 mm lenses. Ip 67 protection rating. Dimmable version RDM-DRS.

Downloads

UM_Archi40_art-1702.pdf
Technical specification
LED type
WHITE 2700K
WHITE 3000K
WHITE 4000K
WHITE 6500K
RED
GREEN
BLUE
AMBER
Number of LEDs
16
Lumen MAX
3500
Lenses
15°
15°x30°
25°
40°
60°
Control type
Protocol USITT DMX512 - RDM
Protocol USITT DMX512 - RDM + Wireless (on request)
Functions
RDM/DRS
Wireless DMX receiver
Input range
100 - 240 VAC; 47/63 Hz
Power (W)
35
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
RAL 9006
Black RAL 9005 (optional)
RAL 9005
White RAL 9010 (optional)
RAL 9010
Marine Grade treatment
None
Yes
IP protection rating
67
Sizes l x p x h (mm)
325 x 140 x 153
Weight (Kgs)
2,6
Product Configurations
  • LED type
  • Number of LEDs
  • Lumen MAX
  • Lenses
  • Control type
  • Functions
  • Input range
  • Power (W)
  • IP protection rating
  • Sizes l x p x h (mm)
  • Weight (Kgs)
  • Mounting systems
  • Colour finishing
    • RAL 9006
    • RAL 9005
    • RAL 9010
  • Marine Grade treatment
  • Product Category

This combination does not exist.
