Descrizione prodotto
Downloads
Specifiche tecniche
Sorgente luce | |
---|---|
Tipo di LED
|
RGBW (5050-20W-RTBH)
|
Numero dei LEDs
|
5
|
Durata di vita dei LED (h)
|
50000
|
Lumen MAX
|
1815
|
Lumen rosso (lm)
|
330
|
Lumen verde (lm)
|
770
|
Lumen blu (lm)
|
110
|
Lumen bianco (lm)
|
715
|
Ottiche | |
Lenti
|
8°
15°
15° x 30°
25°
40°
60°
|
Filtri
|
Nessuno
f 17° tilt
f 34° tilt
f 60°
f 65° tilt
f 100°
f 8°x 60°
|
Controllo | |
Tipo di controllo
|
Protocollo USITT DMX512 - RDM
|
Alimentazione elettrica | |
Alimentazione
|
100 - 277 VAC; 47/63 Hz
|
Potenza (W)
|
20
|
Corrente di spunto
|
|
Specifiche tecniche | |
Grado di protezione IP
|
67
68 optional
|
Sistemi di fissaggio
|
A pavimento/parete
Su tralicci (optional)
|
Dimensioni d x h (mm)
|
134 x 137
|
Peso (Kg)
|
3,8
|
Materiali
|
Vetro temperato 10mm ultra chiaro
|
Finiture | |
Case
|
Aisi 304 (standard)
Aisi 316 (optional)
Aluminium (optional)
Aluminium - Marine Grade (optional)
|
