Descrizione prodotto
Downloads
Specifiche tecniche
Sorgente luce | |
---|---|
Tipo di LED
|
RGBW (5050-20W-RTBH)
|
Numero dei LEDs
|
15
|
Durata di vita dei LED (h)
|
50000
|
Lumen MAX
|
8500
|
Lumen rosso (lm)
|
1750
|
Lumen verde (lm)
|
3450
|
Lumen blu (lm)
|
500
|
Lumen bianco (lm)
|
3300
|
Ottiche | |
Lenti
|
8°
15°
15° x 30°
25°
40°
60°
|
Filtri
|
Nessuno
f 60°
f 100°
f 8°x 60°
|
Controllo | |
Tipo di controllo
|
Protocollo USITT DMX512 - RDM
Protocollo USITT DMX512 - RDM + Wireless (a richiesta)
|
Funzioni e Configurazione | |
Funzioni
|
RDM/DRS + pannello di controllo touch
Wireless DMX receiver
|
Alimentazione elettrica | |
Alimentazione
|
100 - 277 VAC; 47/63 Hz
|
Potenza (W)
|
100
|
Corrente di spunto
|
|
Specifiche tecniche | |
Sistemi di fissaggio
|
A pavimento/parete
Su tralicci (optional)
|
Finitura colore
|
Grigio RAL 9006 (standard)
Nero RAL 9005 (optional)
Bianco RAL 9010 (optional)
Qualsiasi RAL (optional)
|
Trattamento Marine Grade
|
No
Si
|
Grado di protezione IP
|
67
|
Dimensioni l x p x h (mm)
|
925 x 163 x 160
|
Peso (Kg)
|
6,7
|
Categoria Prodotto
|
Linear Bar
|
