TERRA WL5 POB PLUG-IN (it. 210300)
On-board power supply (POB). IP 67 stainless steel AISI 304 inground lighting fixture suitable for for outdoor installations. It includes n.10 x 10W Monochromatic Leds. Plug-In version.
Specifications
| Lighting source | |
|---|---|
| LED type | WHITE 2700K, WHITE 4000K, WHITE 6500K, RED, GREEN, BLUE, AMBER |
| Number of LEDs | 10 |
| LED expected lifetime (hrs) | 50000 |
| Lumen source (lm) | 2500 |
| Optics | |
|---|---|
| Lenses | 4° , 8°, 10°x30°, 15°, 25°, 40°, 60° |
| Filters (optional) | None, Filter f17° tilt, Filter f34° tilt, Elliptical projection filter 60° x n° (n° = native lens) horizontal, Elliptical projection filter n° x 60° (n° = native lens) vertical, Filter f65° frost |
| Connections | |
|---|---|
| Connectors and cables | Main Power: 3x1mm cable H05 1,5mt |
| Connettori e cavi (optional) | Cable: type and length (optional) |
| Control | |
|---|---|
| Control type | Plug-in |
| Power supply | |
|---|---|
| Input range | 100 - 277 VAC; 47/63 Hz |
| Power max (W) | 18 |
| Current | 0,07A@230VAC |
| Physical | |
|---|---|
| IP protection rating | 67, 68 optional |
| Materials | Ultra clear 10mm tempered glass, All in stainless steel AISI304 |
| Mounting systems | Inground |
| Weight (Kgs) | 4 |
| Dimensions d x h (mm) | 190 x 74,6 mm |
| Product Category | Inground |
| IK grade protection | 08 |
| Finishings | |
|---|---|
| Case | AISI 304 (standard), AISI 316 (optional), Aluminium (optional), Aluminium - Marine Grade (optional) |
| Others | |
|---|---|
| FILTER-SING 105-W (art.900419) | No, Yes |
| FILTER-SING 105 (art.900420) | No, Yes |
| FILTER-DOUB 105 (art.900421) | No, Yes |
| Plastic Case TER (art.900537) | No, Yes |
