TERRA PLUS TL/316SS PLUG-IN M (it. 207300)

TERRA PLUS TL/316SS PLUG-IN M (it. 207300)

https://www.studiodue.com/web/image/product.template/218/image_1920?unique=842593b

IP67 protection rating inground LED fixture in stainless steel AISI 316. 24 Monochromatic LEDs. On-board power supply. Tilt adjustment -2° +10° by factory on request.

Not Available For Sale

  • LED type
  • Number of LEDs
  • Lumen max source (lm)
  • Lenses
  • Filters (optional)
  • Connectors and cables
  • Control type
  • Input range
  • Power max (W)
  • Current
  • Tilt
  • IP protection rating
  • IK grade protection
  • Dimensions d x h (mm)
  • Weight (Kgs)
  • Materials
  • Mounting systems
  • Colour finishing
  • Product Category
  • Plastic Case TER-PLUS (art.900536)
  • FILTER-SING TERRA PLUS (art.900417)
  • FILTER-DOUB TERRA PLUS (art.900418)

This combination does not exist.

LED type WHITE 2700K, WHITE 4000K, WHITE 6500K, RED, GREEN, BLUE, AMBER
Number of LEDs 12
Lumen max source (lm) 6000
Lenses 4° , 8°, 15°, 15°x30°, 25°, 40°, 60°
Filters (optional) None, Filter f17° tilt, Filter f34° tilt, Elliptical projection filter 60° x n° (n° = native lens) horizontal, Elliptical projection filter n° x 60° (n° = native lens) vertical
Connectors and cables Main Power: 3x1mm cable H07 0,6mt
Control type Plug-in
Input range 100 - 277 VAC; 47/63 Hz
Power max (W) 42
Current 0,19A@230VAC
Materials Ultra clear 12mm tempered glass, All in stainless steel AISI316
Tilt -2° / +10°
IP protection rating 67
IK grade protection 08
Dimensions d x h (mm) 290 x 200
Weight (Kgs) 5,5
Mounting systems Inground
Colour finishing None
Product Category Inground
Plastic Case TER-PLUS (art.900536) No, Yes
FILTER-SING TERRA PLUS (art.900417) No, Yes
FILTER-DOUB TERRA PLUS (art.900418) No, Yes
Contact Us


IP67 protection rating inground LED fixture in stainless steel AISI 316. 24 Monochromatic LEDs. On-board power supply. Tilt adjustment -2° +10° by factory on request.
