Product Description


Downloads

UM_Archiled200 wb-m_art-17011-17012_low.pdf
Technical specification
Icon attribute
Icon attribute
Icon attribute
LED type
WHITE 2700
WHITE 4000
WHITE 6500
RED
GREEN
BLUE
AMBER
Lumen MAX
9000
Lenses
15°
15° x 30°
25°
40°
60°
Control type
Protocol USITT DMX512 - RDM + Wireless (on request)
DALI DT6
DMX - RDM + DALI + Wireless
Functions
LED display with flip function
DMX or Auto Mode with Master-Slave function
Intelligent temperature control
Continuous dimming 0-100%
Smooth dimming function
Halogen simulation
CYM simulation
Flicker-free function
Setup
RDM/DRS + touch control panel
DMX channels
3ch - 1ch
Input range
100 - 240 VAC; 47/63 Hz
Power (W)
75
Materials
Ultra clear 4mm tempered glass
PMMA lenses
Aluminium alloy housing
Polyester powder coated
Mounting systems
Surface
Truss (optional)
Colour finishing
Black RAL 9005 (standard)
Grey RAL 9006 (optional)
White RAL 9010 (optional)
Marine Grade treatment
None
Yes
IP protection rating
IP 67
Operating temperature
-30°C +45°C
Sizes l x p x h (mm)
270 x 100 x 303
Weight (Kgs)
5
Product Category
Spot
Accessories - Flight case
None
Yes
Accessories - Anti glare
None
Yes
Accessories - Barn door
None
Yes
