Product Description


Downloads
Technical specification
LED type
WHITE 2700
WHITE 4000
WHITE 6500
RED
GREEN
BLUE
AMBER
Number of LEDs
30
Lumen MAX
12000
Lenses
15°
15° x 30°
25°
40°
60°
Filters
None
f 80°
f 100°
f 8°x 60°
Control type
Plug-in
Functions
N/A
Input range
100 - 240 VAC; 47/63 Hz
Power (W)
100
Mounting systems
Surface
Truss (optional)
Colour finishing
Grey RAL 9006 (standard)
Black RAL 9005 (optional)
White RAL 9010 (optional)
Marine Grade treatment
None
Yes
IP protection rating
IP 67
Sizes l x p x h (mm)
925 x 163 x 160
Weight (Kgs)
6
Product Category
Linear Bar
Product Configurations
  • LED type
  • Number of LEDs
  • Lumen MAX
  • Lenses
  • Filters
  • Control type
  • Functions
  • Input range
  • Power (W)
  • IP protection rating
  • Sizes l x p x h (mm)
  • Weight (Kgs)
  • Mounting systems
  • Colour finishing
  • Marine Grade treatment
  • Product Category

This combination does not exist.
